Technical Specifications

Weatherproofing

Built from marine-grade plywood coated inside and out with a rugged, UV-resistant polyurea finish rated IP55. All fasteners and the grille are stainless steel for maximum corrosion resistance in sustained outdoor use.

Build and Mounting

Stainless steel mesh grille with polyester fibre fabric. Ships with a Euroblock connector and cover plate; horizontal and vertical brackets sold separately.

Amplifier Compatibility

Runs at 8 ohms and is recommended for use with Quest QX or QXD amplifiers.

Applications

Suited to outdoor hospitality, retail, and commercial spaces needing weather-resistant sound at Qi8 output levels.

Key Specifications

  • Driver Configuration: 1-inch compression driver, 8-inch woofer
  • Impedance: 8 ohms
  • Dispersion / Horn: 90 x 70 degrees, rotatable horn
  • Power Handling (RMS/Peak): 200W / 400W
  • Frequency Response (-6dB): 60Hz to 20kHz
  • Sensitivity (1W @ 1m): 94.1dB
  • Maximum SPL @ 1m: 123.2dB
  • IP/Weather Rating: IP55
  • Mounting and Included Brackets: Euroblock connector and cover plate included; horizontal (HBRQi8) and vertical (VBRQi8) brackets sold separately
  • Cabinet Material and Finish: Marine plywood with marine-grade UV-resistant polyurea coating; stainless steel mesh grille with polyester fibre fabric
  • Amplifier Compatibility: Quest QX or QXD Series amplifiers
  • Dimensions: 440 x 270 x 270mm (H x W x D)
  • Weight: 11.1kg
