KLANG:vokal Immersive In-Ear Mixing Processor
KLANG:vokal Immersive In-Ear Mixing Processor

KLANG:vokal Immersive In-Ear Mixing Processor

Brand: KLANG
Categories: In-ear monitoring
SKU: KG-VOKAL

KLANG:vokal is a 1U immersive in-ear mixing processor that gives up to 12 performers their own 3D in-ear mix, with 24 mono or stereo inputs per mix drawn from 64 mono inputs. Dante and MADI BNC I/O are built in at 48kHz or 96kHz, along with word clock connections, placing it between KLANG:1 and KLANG:konductor for bands, theatre and worship.

Pairs well with

Technical Specifications

Immersive Processing

KLANG:vokal offers 12 immersive in-ear mixes, each with 24 mono or stereo inputs chosen from 64 Dante and MADI inputs, at 48kHz or 96kHz. Root-Intensity EQs are available for all 64 inputs and all 12 mixes. The optional vokal+ upgrade unlocks all 64 inputs per mix.

Connectivity

Mixes are sent over Dante to KLANG:kontroller or back to a mixing console over MADI or Dante. A front PoE port powers a KLANG:kontroller directly.

Applications

House of worship, theatre, studio and broadcast installations.

Key Specifications

  • Immersive mixes: 12
  • Inputs per mix: 24 mono or stereo from 64 (64 with vokal+)
  • Dante: 64 x 64 (48kHz and 96kHz)
  • MADI: BNC, 64 x 64 @ 48kHz / 32 x 32 @ 96kHz
  • Processing latency: 1/4 ms
  • Word clock: In and out
  • Network ports: 2 x etherCON Dante, 2 x etherCON control, 1 x PoE front port
  • Power: IEC, 110-240VAC
  • Rack size: 1U
  • Weight: 3.6kg
Downloads
