Categories: Point source & monitors
SKU: 10M003

The EMS-61 is a compact two-way passive loudspeaker designed to work equally well as a stand-alone box or as the top element in a full-range system when paired with an EM Acoustics subwoofer such as the S-12 or S-15. Its multi-angle cabinet lets it serve as front-of-house fill, a compact stage monitor, or a fixed-install loudspeaker without changing hardware.

Pairs well with

Technical Specifications

Drivers and Dispersion

A 6.5-inch neodymium low-frequency driver is coupled to a 1-inch exit neodymium compression driver loaded onto a rotatable 90 x 60 degree constant-directivity waveguide. The rotatable horn keeps coverage consistent whether the box is oriented horizontally or vertically, and the reflex-loaded cabinet is shaped to support both orientations plus monitor-wedge use.

Cabinet and Rigging

The birch-plywood enclosure is finished in impact- and weather-resistant textured polyurethane, black or white as standard with RAL matching available. Threaded fixings accept OmniMount Series 30 and Powerdrive Series 75 brackets, and a stainless-steel grille backed with acoustic fabric protects the drivers.

Amplification and Processing

The EMS-61 needs a single amplifier channel capable of 300-500W RMS into 8 ohms. It is a true passive design and needs no active DSP for correct operation, though external high-pass filtering and limiting are recommended for system protection when run from EM Acoustics' Advanced System Amplifiers.

Applications

Front-of-house and fill sound reinforcement for theatre, corporate AV, and installed venues, with stage-monitor capability.

Key Specifications

  • Frequency Response: 80Hz to 20kHz, plus/minus 3dB
  • Dispersion: 90 x 60 degrees, rotatable (-6dB points)
  • Maximum SPL: 118dB continuous, 124dB peak
  • Driver Complement: 1 x 6.5-inch (165mm) neodymium LF, 1 x 1-inch (25mm) exit neodymium HF
  • Nominal Impedance: 8 ohms
  • Power Handling: 200W RMS, 400W programme
  • Connectors: 2 x Neutrik speakON NL4
  • Rigging Points: OmniMount Series 30 / Powerdrive Series 75 compatible fixings
  • Enclosure Material and Finish: Multi-laminate birch plywood, textured polyurethane (black/white standard, RAL on request)
  • Dimensions (W x H x D): 195 x 368 x 208mm
  • Weight: 7kg net
