DiGiCo Quantum 326 Digital Mixing Console

DiGiCo Quantum 326 Digital Mixing Console

Brand: DiGiCo
Categories: Consoles
SKU: Q326-WS

The Quantum 326 is the compact sibling of the Quantum 338, delivering the same processing power in a narrower frame with 24+2 faders and two touchscreens. It provides 128 fully processed input channels, 64 output busses and a 24 x 24 matrix, with Mustard Processing, Spice Rack and Nodal Processing built in, plus 32-bit local mic/line I/O, six BNC MADI ports and two DMI expansion slots.

Pairs well with

Technical Specifications

Control Surface

Two 17-inch, 1000-nit high-brightness multitouch screens carry the meter bridge and soft quick-select buttons. 26 x 100mm touch-sensitive motorised faders are laid out in two banks of 12 plus two user-assignable faders, with 51 individual TFT channel displays and a dark mode for low-light environments.

Conversion and I/O

Local connectivity uses DiGiCo's 32-bit Ultimate Stadius ADC/DAC conversion: 8 mic/line inputs, 8 line outputs and 8 AES channels. The console offers six MADI interfaces at 48kHz (three at 96kHz) on BNC, two DMI slots, optional dual-loop Optocore and a built-in UB MADI USB recording interface.

Processing

Mustard Processing (36 strips), Spice Rack (8 mono / 4 stereo slots), 64 Nodal Processing instances and True Solo are included. The optional Pulse upgrade raises the console to 156 inputs, 72 busses, 48 Mustard strips and 72 Nodal processors.

Applications

Live sound, touring, theatre, house of worship and installed sound where Quantum 338 power is needed in a smaller footprint.

Key Specifications

  • Input channels: 128 with full processing (156 with Pulse)
  • Busses: 64 aux/sub-group (72 with Pulse)
  • Matrix: 24 x 24, full processing
  • Faders: 26 x 100mm motorised, touch-sensitive
  • Screens: 2 x 17-inch high-brightness multitouch
  • Dynamic EQ: 286 instances
  • Local I/O: 8 x 32-bit mic/line in, 8 line out, 8 x AES
  • MADI: 6 interfaces @ 48kHz / 3 @ 96kHz (BNC)
  • DMI slots: 2
  • GPI/GPO: 16
  • Sample rate: 48kHz / 96kHz
  • Dimensions: 1124mm (W) x 805mm (D) x 482mm (H)
  • Weight: 52kg
